VTZ(SC)-12GD sab hauv tsev peb-txoj hauj lwm lub tshuab nqus tsev vacuum breaker yog cov khoom siv hluav taws xob sib xyaw ua ke, kev sib koom ua ke hauv kev sib cais, hloov hauv av, thiab lub tshuab nqus tsev vacuum.

Khoom Specifications

Daim ntawv Specification

Tsis muaj.	Lub npe	Chav tsev	Cov ntaub ntawv
1	Rated Voltage	kV ua	12
2	Rated Zaus	Hz	50/60
3	RatedCurrent	A	630/1250
4	RatedPtus tswv Fkev xav tauWtivVoltage	kV ua	48(Ntawm qhov chaw sib cuag) / 42(Rau hauv av)
5	RatedLightnhauvImpulseWtivVoltage	kV ua	75
6	RatedShort-Circuit uaBreakingCurrent	kA	25/31.5
7	Rated Short-Circuit uaMkevCurrent (Peak)	kA	63/80
8	RatedWtivCurrent (Peak)	kA	63/80
9	RatedDuration ntawmShort-Circuit ua	s	4
10	Kev khiav haujlwmCycles uaRatedShort-Circuit uaBreakingCurrent	Lub voj voog	E2
11	Neeg kho tshuabEkev ua siab ntev	Sijhawm	10000
12	Standard Kev Ua HaujlwmSsib npaug	-	O-0.3s-CO-180s-CO
13	Tso cai Wpob ntsegThickness ntawmCtiv	mm	Tsawg dua los yog sib npaug 3

Neeg kho tshuabCharacteristics

Tsis muaj.	Lub npe	Chav tsev	Cov ntaub ntawv
1	Clearance ntawmTsiv thiab Kho Ctiv	mm	9±1
2	Hu rauHla mus ncig	mm	3.5±0.5
3	Nruab nrabCpoobSpeb	m/s	0.6±0.2
4	Nruab nrabOpeningSpeb (Anruab nrabSpebntawm First Openingntawm6mm)	m/s	1.1±0.2
5	RatedCtiv Siab	N	2500±200N(25 kA) 3100±200N(31,5k ua)
6	Lub Sijhawm Kaw	ms	30-70
7	Sijhawm qhib	ms	20-50
8	Hu rauBua ounceDuration ntawmCpoobOkev ua txhaum	ms	Tsawg dua los yog sib npaug2
9	Tsis-Simultaneity ntawmKaw/Opening Kev ua haujlwmntawm 3-Phase	ms	Tsawg dua los yog sib npaug 2

Khoom zoo

Kev ua haujlwm ntawm Circuit Court breaker: E2-C2-M2

Kev saib xyuas yooj yim: modular mechanism tsim tso cai rau kev hloov pauv yooj yim ntawm qhov kaw thiab qhib coils yam tsis tas yuav tsum tau dismantling lwm yam khoom. Qhov no tshem tawm qhov kev xav tau ntawm kev sim lossis kev hloov kho tom qab hloov pauv, ua kom cov neeg siv hloov lawv tus kheej, ua rau kev saib xyuas tom qab tau yooj yim dua.

Kev sib xyaw ua ke siab: tus qauv tsim txais cov qauv tsim qauv uas muaj kev sib koom ua ke nrog kev sib cais cov keyboards, Circuit Court breakers, grounding keyboards, sensors, interlocking mechanisms, thiab lwm yam.

Cov neeg siv-phooj ywg ua haujlwm kev nyab xeeb: qhov yuam kev sib cuam tshuam ntawm cov keyboards cais, Circuit Court breakers, thiab grounding keyboards tiv thaiv kev ua haujlwm tsis raug.

Compact tsim: qhov tsawg tshaj plaws hauv txee qhov ntev yog 500 x 1000 x 1800 (mm).

Khoom

Daim ntawv thov

Haum rau 3.6 ~ 12kV fais fab daim phiaj

Kev tiv thaiv thiab tswj units rau industrial thiab mining enterprises

Kev faib tawm hauv nroog hauv zej zog

Product Outline Drawing

VTZSC-12GD Indoor Three-Position Vacuum Circuit Breaker manufacturer

Lus ceeb toom:

VTZ(SC)-12GD sab hauv tsev peb-txoj hauj lwm lub tshuab nqus tsev Circuit Court breaker tuaj yeem ntsia tau rau hauv txoj hauj lwm inverted.

Secondary Wiring Diagram

VTZSC-12GD Indoor Three-Position Vacuum Circuit Breaker factory
